Mahle 2290420 - Piston with rings and pin

Mahle 2290420 - Piston with rings and pin

£168.12 GBP
£169.82 GBP £168.12 GBP
Inc. VAT
Sale Sold out
Pop-up link text

In Stock & ready for next working day delivery

Estimated lead time 2-3 working days. Subject to availability.

Get the best deal with Duco's Price Match Policy

View full details
This is Mahle 2290420 - Piston with rings and pin



Cylinder Bore [mm]: 128,0 mm
Length [mm]: 141,8 mm
Compression Height [mm]: 89,35 mm
Bolt Length [mm]: 105,0 mm
Bolt Head Diameter [mm]: 46,0 mm
Recess Depth 1 [mm]: 22,0 mm
Recess Diameter [mm]: 80,0 mm
Valve Pocket Depth 1 [mm]: 2,1 mm
Valve Pocket Depth 2 [mm]: 1,9 mm
Machined: with cut-out for oil jet
Surface: Coated
Supplementary Article/Info 2: with piston ring carrier
Supplementary Article/Info 2: without cooling duct
Top Land Height [mm]: 18,45 mm
Production Number: 128 L 74
Piston Clearance [mm]: 0,14 mm
Component Number: 1. T 4.0 Cr
Component Number: 2. M 3.0 Cr P
Component Number: 3. DSF 4.0 Cr
Packaging length [cm]: 15,0 cm
Packaging width [cm]: 15,00 cm
Packaging height [cm]: 21,00 cm
Net Weight [g]: 3830 g



MAN

Feel free to contact us at support@ducocarparts.co.uk should you wish to double check!



Before sending out your ordered part(s), we perform a compatibility check to guarantee that they will fit your vehicle. This verification can be done by using your registration number (UK) or the last 7 digits of your VIN. Kindly provide your car information before proceeding to checkout.



MAHLE-2290420



Manufactured by

Mahle
