• Mahle 0380900 - Piston with rings and pin
1 1

Mahle

Mahle 0380900 - Piston with rings and pin

Mahle 0380900 - Piston with rings and pin

£195.72 GBP
£197.70 GBP £195.72 GBP
Inc. VAT
Sale Sold out
Pop-up link text

In Stock & ready for next working day delivery

Estimated lead time 2-3 working days. Subject to availability.

Get the best deal with Duco's Price Match Policy

View full details
This is Mahle 0380900 - Piston with rings and pin



Cylinder Bore [mm]: 120,64 mm
Length [mm]: 144,5 mm
Compression Height [mm]: 92,5 mm
Bolt Length [mm]: 98,0 mm
Bolt Head Diameter [mm]: 52,0 mm
Recess Depth 1 [mm]: 21,8 mm
Recess Diameter [mm]: 67,5 mm
Valve Pocket Depth 1 [mm]: 2,0 mm
Machined: with cut-out for oil jet
Surface: Coated
Supplementary Article/Info 2: with piston ring carrier
Production Number: 121 L 10
Component Number: 1. T 3.5 IF Mo
Component Number: 2. M3.16 IW Cr
Component Number: 3. DSF4.747 Cr
Packaging length [cm]: 15,0 cm
Packaging width [cm]: 15,00 cm
Packaging height [cm]: 21,00 cm
Net Weight [g]: 3700 g



Volvo TD103E TD103EA TD103ES TD103ME TD103KAE TD103KBE TD103KCE TD104KAE TWD1030ME

Feel free to contact us at support@ducocarparts.co.uk should you wish to double check!



Before sending out your ordered part(s), we perform a compatibility check to guarantee that they will fit your vehicle. This verification can be done by using your registration number (UK) or the last 7 digits of your VIN. Kindly provide your car information before proceeding to checkout.



MAHLE-0380900



Manufactured by

Mahle
