This is Mahle 0100502 - Piston with rings and pin



Cylinder Bore [mm]: 72,6 mm
Length [mm]: 46 mm
Compression Height [mm]: 26 mm
Bolt Length [mm]: 49 mm
Bolt Head Diameter [mm]: 17,98 mm
Recess Depth 1 [mm]: 7,77 mm
Recess Diameter [mm]: 57,8 mm
Valve Pocket Depth 1 [mm]: 1 mm
Valve Pocket Depth 2 [mm]: 1,2 mm
Surface: Coated
Top Land Height [mm]: 5,7 mm
Production Number: 72 L 49
Piston Clearance [mm]: 0,03 mm
Component Number: 1. R 1.0 IF N
Component Number: 2. M 1.2 IFU
Component Number: 3. DSF 2.0 P
Packaging height [cm]: 12,80 cm
Net Weight [g]: 278 g
Packaging length [cm]: 9,5 cm
Packaging width [cm]: 9,50 cm



FIAT
