CTS Turbo is proud to aounce the release of the BOSS500 for FSI (timing-belt motor) owners.
After a long and tedious R&D process, our engineers have finalized this turbo upgrade kit to create a modular package that is capable of producing upwards of 600hp and has the long-term reliability.
At the heart of our aptly named BOSS (Bolt-On Speed Solution), FSI upgrade kit uses our own CTS CHRA, it is installed into a CTS proprietary exhaust housing. The housing is carefully cast and machined in house to be compatible with any exhaust downpipe and the scroll area was designed to be approximately 0.63AR. This results is an excellent boost response and eliminates any possible restriction.
Don't be fooled by other manufacturers putting a larger turbo into a stock housing. It is not beneficial, and that is why we made our own!
Custom oil/water lines complete this kit to offer simple installation, simple tuning, and problem-free operation.
Proprietary custom molded silicon hoses coect the turbo to your turbo outlet pipe and intake.
Currently, the BOSS turbo upgrade is only compatible with CTS Turbo intake, however, other intakes could be made to work unfortunately, we caot provide guidance for installing other manufacturer's intakes.
You can use a CTS Turbo or other billet diverter/blow-off valve. Only OEM or CTS turbo outlet pipe is compatible at this time.
MK6 Golf R or 8P Audi S3 will require a DV block-off plate, please see below.
Product contents:
CTS Turbo 50/67 dual ball-bearing CHRA with 11 blade compressor wheel
CTS Turbo exhaust housing
CTS Turbo wastegate bracket
CTS Turbo 4-ply silicone couplers
CTS Turbo oil lines
CTS Turbo water lines
Hardware required for installation
Product features:
400hp to 500hp capable (depending on fueling and engine mods)
Direct bolt-on without any modifications to the car
Compatible with CTS Turbo intake and factory DV or CTS DV/BOV
Compatible with factory or CTS Turbo turbo outlet pipe
Compatible with any exhaust downpipe
Tuning available for stock fueling and for upgraded fueling from United Motorsport and Eurodyne
| Weight | 40 lbs |
| Dimensions | 32 x 15 x 13 in |
