034Motorsport is proud to unveil an all-new line of Performance Software for B8/B8.5 Audi S4/S5 & Q5/SQ5 models equipped with the powerful 3.0 TFSI Supercharged V6 engine!

Flashed directly through your vehicle's OBD-II port, 034Motorsport's proprietary calibrations for the Simos 8 ECU safely and effectively increase the power output of the 3.0 TFSI engine. The result is a noticeable improvement in acceleration and throttle response, without any sacrifice in driveability or reliability.

034Motorsport's 3.0 TFSI Performance Software was developed entirely in-house on 034Motorsport's Development B8 Audi S4. The calibrations were then refined on multiple enthusiast-owned B8/B8.5 Audi S4/S5 vehicles before release.

034Motorsport Performance Software is a must-have for any B8/B8.5 Audi S4/S5 & Q5/SQ5 powered by the 3.0 TFSI Supercharged V6 engine. 034Motorsport 3.0 TFSI tunes are flashed directly through the factory OBD-II port using the 034Motorsport Dynamic+ End User Flashing Kit, and offer dramatic increases in horsepower and torque throughout the powerband. The 034Motorsport Dynamic+ End User Flashing Kit allows customers to install their 034Motorsport Dynamic+ Performance Software themselves. In addition, End User Flashing allows Dynamic+ Performance Software customers to receive and install software updates and revisions, flash back to stock, or upgrade to the next stage of performance software for their vehicle.

Stock: 332 HP / 318 TQ (91 Octane)
Stage 1: 430 HP / 374 TQ (91 Octane)
Stage 2: 450 HP / 387 TQ (91 Octane)
Stage 2+: 496 HP / 467 TQ (E40 Blend)

Please Note: Use this product page only if you plan to flash this software to your ECU yourself. To install this software you must have a 034Motorsport Dynamic+ End User Flashing Kit. If you do not have our Dynamic+ End User Flashing Kit, click the check box below to add this to your order, otherwise you will not be able to flash this software to your ECU. If you already have a Dynamic+ End User Flashing Kit, simply purchase the software without adding the flashing kit

Alternatively, this 034Motorsport Dynamic+ Performance Software can be installed for you, without the need to purchase the End User Flashing Kit, at 034Motorsport's Service Department in Fremont, CA, as well as the 034Motorsport Dynamic+ Performance Software Dealers listed here. Dealer flashes must be purchased directly through the dealer facility (including 034Motorsport's Service Department), not through this product page.

Software Features

• Increased Horsepower & Torque Throughout the Powerband
• Improved Power Delivery, Acceleration, and Driving Characteristics
• Available in 91 Octane, 93 Octane, and 100 Octane Calibrations
• Refined Throttle Mapping for Enhanced Throttle Response & Precision
• Raised RPM Limit to 7,200 for Broader Powerband
• Speed Limiter Removed for Increased Top Speed
• Track-Tested Calibrations Ensure Consistent Power Delivery
• Flashed Directly Via the Factory OBD-II Port

Performance Software Comparison ?(Click to Enlarge)

Performance Software Stage Descriptions

Stage 1

034Motorsport Stage 1 Performance Software for the B8/B8.5 Audi S4/S5/Q5/SQ5 3.0 TFSI is engineered to safely increase horsepower and torque with no hardware modifications required. 034Motorsport's proprietary calibrations increase boost by controlling the supercharger bypass, while optimizing timing and fueling maps to extract additional power from the 3.0 TFSI engine.

Stage 1 Performance Software features a higher redline of 7,200 RPM, resulting in a broader powerband and greater peak horsepower figures than available with the factory 7,000 RPM maximum engine speed. In addition to power improvements, 034Motorsport's engineers spent a significant amount of time refining the throttle mapping in both Dynamic and Comfort modes to provide improved throttle response and allow for more precise throttle modulation. Stage 1 Performance Software also enables left foot braking, which allows for further control of the vehicle when driving on track.

034Motorsport 3.0 TFSI Performance Software is flashed via the factory OBD-II port, and does not require any physical modification of the factory ECU. Stage 1 is available in 91 Octane, 93 Octane, 100 Octane, and 104 Octane files.

Stage 2

034Motorsport Stage 2 Performance Software for the B8/B8.5 Audi S4/S5/Q5/SQ5 3.0 TFSI is engineered to further increase horsepower and torque output over Stage 1 levels with the addition of 034Motorsport's 3.0 TFSI Supercharger Pulley Upgrade. The Supercharger Pulley Upgrade allows for increased boost pressure from the factory Eaton TVS1320 Supercharger throughout the powerband, while 034Motorsport's proprietary calibrations safely yield additional power from the 3.0 TFSI engine.

Stage 2 Performance Software features a higher redline of 7,200 RPM, resulting in a broader powerband and greater peak horsepower figures than available with the factory 7,000 RPM maximum engine speed. In addition to power improvements, 034Motorsport's engineers spent a significant amount of time refining the throttle mapping in both Dynamic and Comfort modes to provide improved throttle response and allow for more precise throttle modulation. Stage 2 Performance Software also enables left foot braking, which allows for further control of the vehicle when driving on track.

034Motorsport 3.0 TFSI Performance Software is flashed via the factory OBD-II port, and does not require any physical modification of the factory ECU. Stage 2 is available in 91 Octane, 93 Octane, 100 Octane, and 104 Octane files.

Dyno Chart (Click to Enlarge)

Manufactured by

034Motorsport

Part Number

034-30-TFSI
