• Mobil SHC GEAR 320 WT DRUM 208Ltr
1 1

Mobil

Mobil SHC GEAR 320 WT DRUM 208Ltr

Mobil SHC GEAR 320 WT DRUM 208Ltr

£2,689.61 GBP
£2,772.22 GBP £2,689.61 GBP
Inc. VAT
Sale Sold out

By placing an order for this item, you agree that this item is a special-order product and is not eligible for refunds or exchanges once the order has been placed.
Pop-up link text

In Stock & ready for next working day delivery

Estimated lead time 2-3 working days. Subject to availability.

Get the best deal with Duco's Price Match Policy

View full details
  • Mobil SHC Gear 320 WT advanced wind turbine gear lubricant is a fully synthetic industrial gear lubricant designed to provide optimum equipment protection for wind turbine gearboxes and extended lubricant life even under extreme conditions.



Specification and Approvals

Property

Grade

ISO 320

Density @ 15.6 C, g/ml, ASTM D4052

0.851

Emulsion, Time to 37 mL Water, 82 C, min, ASTM D1401

15

Flash Point, Cleveland Open Cup, °C, ASTM D92

256

Foam, Sequence II, Tendency, ml, ASTM D892

0

Foam, Sequence II, Stability, ml, ASTM D892

0

FZG Micropitting, Fail Stage, Rating, FVA 54

>10

FZG Micropitting, GFT-Class, Rating, FVA 54

High

FZG Scuffing, A/8.3/90, Fail Stage, Rating, DIN 51354

14+

Kinematic Viscosity @ 100 C, mm2/s, ASTM D445

44.7

Kinematic Viscosity @ 40 C, mm2/s, ASTM D445

343

Pour Point, °C, ASTM D5950

-45

Rust Characteristics, Procedure B, ASTM D665

PASS

Viscosity Index, ASTM D2270

189

ISO 4406 Cleanliness, class, ISO 4407

-/14/11 max



Applications

Mobil SHC Gear 320 WT advanced wind turbine gear lubricant is recommended for lubrication of the main gearbox in wind turbine power generation systems. It is especially recommended for applications that may be subject to micropitting, especially heavily loaded gearboxes with surface-hardened tooth metallurgies, which are typically used in wind turbines. It may also be used in gear applications where extreme low and/or high temperatures are encountered and applications where corrosion may be severe. Compared to conventional gear oil chemistries, Mobil SHC Gear 320 WT advanced wind turbine gear lubricant can provide improved lubrication of gearbox rolling element bearings.

Mobil SHC Gear 320 WT has a recommended operating temperature range of -35 ºC to 100 ºC.

Typical applications include:

Wind turbines, especially highly loaded and shock loaded units, remotely located units and extreme temperature environments

Auxiliary gearboxes in wind turbines, such as gearmotors for pitch and yaw drives

Application consideration: while Mobil SHC Gear 320 WT is compatible with mineral oil-based products, it is recommended that systems are thoroughly cleaned out and flushed before switching to Mobil SHC Gear 320 WT to achieve the maximum performance benefits.



Please compare with your original manufacturer's oil specification which can be found in your vehicle manual. Feel free to contact us if you require any assistance!



Before sending out your ordered part(s), we perform a compatibility check to guarantee that they will fit your vehicle. This verification can be done by using your registration number (UK) or the last 7 digits of your VIN. Simply enter your car information before proceeding to checkout.



MOBIL151469



Manufactured by

Mobil
